Designed to fit your environment

Designed to deliver integrated network printing, scanning and digital copying with more productivity features than any other system in its class, the XES 8825 Digital Document System is a new, powerful ally.

8825 DDS - simplify your work processes and improve productivity.

  • Concurrently handles print and copy jobs
  • Concurrently scans and prints
  • Higher throughout than any competitor product in its class
  • User-friendly copier control panel
  • Preset modes for line, blueprint, and photo
  • 1 or 2 roll capacity, A-E size
  • Job recall and electronic collation
  • Auto reduction/enlargement
  • Easy, flexible system integration
  • Full suite of client software drivers
  • Expands with your needs
  • Optional Scan-to-Net
  • Optional Account Data Tracking
  • Optional Adobe PostScript 3 for enhanced reliability
  • Optional finishing - Folder and Stacker 1000

Features

  • Auto Port sensing
  • Auto data format recognition
  • Auto scaling
  • Auto rotation
  • Auto size detection
  • Auto roll select and switch
  • Remote printer administration
  • Prioritized job queuing
  • Remote job queue management
  • Electronic collation
  • 9 pen palettes (256 pens each)
  • 64 pen patterns, including 15 user-definable patterns
  • Plot labeling with automatic naming and time/date generation
  • Banner pages
  • Page composition/plot overlay
  • Plot stamping with user- downloadable stamps
  • 10 user setups
  • 33 gray scales
  • Media mismatch management
  • Plot nesting
  • Control panel lockout


Contact Us to request further product information.

Technical Specifications for Xerox 8825 Digital Document System

Printer

PROCESS/IMAGING

  • Xerographic LED

PHOTORECEPTOR

  • Organic

MEDIA SUPPLY

  • 1 roll, 500 ft
  • Optional - 2nd Roll
  • Manual sheet bypass

MEDIA TYPE

  • Bond
  • Vellum
  • Film

OUTPUT SIZE

  • Min: 8% x 11 inches
  • Max: 36 inches x 80 feet (print)
  • Max: 36 inches x 1 00 feet (copy)

RESOLUTION

  • 400 dpi

PROCESS SPEED

  • 3 ips

THROUGHPUT

  • Up to 4 D / 2 E per minute

POWER REQUIREMENTS

  • 60 Hz: 115 V/16 A; 50/60 Hz: 220/230-240 V / 10 A

PHYSICAL CHARACTERISTICS

  • Weight Approx. 550 lbs
  • Height 43"
  • Width 57"
  • Depth 23"

FINISHING

  • Standard - Catch Tray-50 E/100 D
  • Optional - Stacker 1000-up to 1000 mixed size prints
  • Optional - Online Folder

AccXES Controller

CPU

  • Power PC 740

MEMORY

  • 64 Mb standard
  • Expandable up to 192 Mb

HARD DISK

  • Standard - 4.5 Gb Ultra SCSI, 7200 rpm, internal drive

DATA FORMATS

  • HP-GL
  • HP-GU2
  • HP-RTL
  • CGM (Level 1 with ATA ext.)
  • C4
  • FileNET, Versatec Data Standards (VRF, ordered vector, blocked raster, compacted raster)
  • CalComp 906/907/951 /PC
  • TIFF 6.0
  • NIRS
  • CALS 1 & 2

COMPRESSION TYPES

(for applicable raster formats)

  • CCITT G4
  • G3-lD
  • G3-2D
  • Packbits
  • RLE
  • Seed Row
  • Adaptive
  • Optional Adobe PostScript 3

INTERFACES

  • Standard - Serial RS-232; IEEE 1284 Bi-directional Centronics; SCSI- 2; VPI; 10/100 Ethernet (TCP/IP) supports 10/100 Base T
  • Optional - 10 mbs Network Interface Card supports 10 Base T and 10 Base2ÊNetwork Standard - TCP/IP with lpr/lpd

PROTOCOLS

  • Optional- Novell IPX/SPX Pserver 3.1/4.1 with NDS
  • Ethertalk
  • NetBEUI

CLIENT SOFTWARE

  • ADI drivers for AutoCAD Rl2/13/14
  • Print Drivers for Win 95/98/NT
  • Web Print Manager Tool for WinÊ95/98/NT/Solaris
  • Document Submission Tool for Win 95/98/NT
  • Document Retrieval Tool for Win 95/98/NT/Solaris
  • Optional - Adobe PostScript 3 Drivers for Windows 95/98/NT

Scanner

RESOLUTION

  • 400 dpi

SPEED

  • 2 ips at 400 dpi (copy and scan)
  • 2.67 ips at 300 dpi (scan)
  • 4 ips at 200 dpi (scan)

INPUT

  • Min: 4% x 5@ inches
  • Max: 41 inches x 1 00 feet (only will capture 36" of image)
  • Edge/Center Adjustment Lead and trail edge adjust/ center alignment

SCAN TO NET

  • Optional - indexing
  • Scan preview
  • Link to raster editor
  • Resolution selection
  • TIFF 6.0 data format
  • TCP/IP Ethernet interface

POWER REQUIREMENTS

  • 50/60 Hz; 120/240 V; 20 A

Copier

REDUCTION ENLARGEMENT

  • 25 to 400% in 0. 1 % increments

OUTPUT SELECTION

  • Auto/Manual Roll Selection and Scaling

CONCURRENCY

  • Scanning/Copying/Printing
  • Printer Interrupt Key

Digital Retention

  • Up to 999 copies from a set of 100 standard E size drawings

SETS BUILD

  • Electronic Collation
  • Forward
  • Reverse
  • Last Scan Replacement
  • Rescale and Reprint without Rescanning
  • 999 copies from a set of 1 00 standard E size drawings.

IMAGING

  • Inverse
  • Rotation
  • 7 copy contrast levels

AUTO IQ

  • Automatic background suppression/width detection of original

COPY MODES

  • Line
  • Mixed
  • Photo

Options

  • Additional SDRAM Modules in 64 Mb Increments
  • Stacker 1000
  • Online Folder
  • Adobe PostScript 3
  • 10 mbs Network Interface Card (supports IPX/SPX, NetBEUI and Ethertalk)
  • Manual Sheet Bypass
  • 2nd Media Roll
  • Account Data Tracking
  • Scan-to-Net


Agency approvals: UL and CSA

Product data subject to change without notice.
